轴径 | 连座轴承 型号 | 外形尺寸(mm) | 螺栓 规格 | 轴承 型号 | 座型号 | 重量 (Kg) | ||||||||||
d | H | L | J | A | N | N1 | H1 | Ho | S | B | ||||||
(min.) | (mm) | |||||||||||||||
7/8 15/16
1 |
25 | UCP305-14 305-15 305 305-16 | 45 | 173 | 132 | 45 | 17 | 20 | 15 | 85 | 15 | 38 | M14 | UC 305-14 305-15 305 305-16 | P305 | 1,4 |
1- 1/8
1-3/16 |
30 | UCP306-18 306 306-19 | 50 | 180 | 140 | 50 | 17 | 20 | 15 | 95 | 17 | 43 | M14 | UC306-18 306 306-19 | P306 | 1,8 |
1- 1/4 1- 5/16 1- 3/8 |
35 | UCP307-20 307-21 307-22 307 | 56 | 210 | 160 | 56 | 17 | 25 | 19 | 106 | 19 | 48 | M14 | UC307-20 307-21 307-22 307 | P307 | 2,8 |
1- 1/2 1- 9/16 |
40 | UCP308-24 308-25 308 | 60 | 218 | 170 | 62 | 18 | 25 | 19 | 116 | 19 | 52 | M14 | UC308-24 308-25 308 | P308 | 3,0 |
1-5/8 1-11/16 1-3/4 |
45 | UCP309-26 309-27 309-28 309 | 67 | 244 | 190 | 66 | 20 | 26 | 23 | 129 | 22 | 57 | M16 | UC309-26 309-27 309-28 309 | P309 | 4,1 |
1-7/8 1-15/16 |
50 | UCP310-30 310-31 310 | 75 | 271 | 212 | 74 | 20 | 30 | 26 | 143 | 22 | 61 | M16 | UC310-30 310-31 310 | P310 | 5,8 |
2 2-1/8
2-3/16 |
55 | UCP311-32 311-34 311 311-35 | 80 | 300 | 236 | 80 | 20 | 32 | 29 | 154 | 25 | 66 | M16 | UC311-32 311-34 311 311-35 | P311 | 7,4 |
2-1/4
2-3/8 2-7/16 |
60 | UCP312-36 312 312-38 312-39 | 85 | 325 | 250 | 85 | 23 | 35 | 31 | 164 | 26 | 71 | M20 | UC312-36 312 312-38 312-39 | P312 | 9,4 |
2-1/2 |
65 | UCP313-40 313 | 90 | 335 | 260 | 90 | 25 | 38 | 33 | 176 | 30 | 75 | M20 | UC313-40 313 | P313 | 10 |
2-3/4 |
70 | UCP314-44 314 | 95 | 360 | 280 | 93 | 27 | 40 | 34 | 187 | 31 | 78 | M22 | UC314-44 314 | P314 | 12 |
3 |
75 | UCP315 315-48 | 100 | 380 | 290 | 100 | 27 | 40 | 35 | 198 | 32 | 82 | M22 | UC315 315-48 | P315 | 14 |
80 | UCP316 | 106 | 400 | 300 | 105 | 27 | 40 | 37 | 210 | 34 | 86 | M22 | UC316 | P316 | 18 | |
3- 1/4 |
85 | UCP317-52 317 | 112 | 420 | 320 | 110 | 33 | 45 | 40 | 220 | 40 | 96 | M27 | UC317-52 317 | P317 | 20 |
3-1/2 |
90 | UCP318-56 318 | 118 | 430 | 330 | 110 | 33 | 45 | 40 | 234 | 40 | 96 | M27 | UC318-56 318 | P318 | 24 |
3-3/4 | 95 | UCP319 319-60 | 125 | 470 | 360 | 120 | 36 | 50 | 45 | 248 | 41 | 103 | M30 | UC319 319-60 | P319 | 29 |
4 | 100 | UCP320 320-64 | 140 | 490 | 380 | 120 | 36 | 50 | 50 | 275 | 42 | 108 | M30 | UC320 320-64 | P320 | 35 |
110 | UCP322 | 150 | 520 | 400 | 140 | 40 | 55 | 55 | 300 | 46 | 117 | M33 | UC322 | P322 | 45 | |
120 | UCP324 | 160 | 570 | 450 | 140 | 40 | 55 | 65 | 320 | 51 | 126 | M33 | UC324 | P324 | 55 | |
130 | UCP326 | 180 | 600 | 480 | 140 | 40 | 55 | 75 | 355 | 54 | 135 | M33 | UC326 | P326 | 72 | |
140 | UCP328 | 200 | 620 | 500 | 140 | 40 | 55 | 75 | 390 | 59 | 145 | M33 | UC328 | P328 | 89 |
